CFM, ICFM, ACFM, SCFM: Why so many volumetric flow rates?

Air Compressor

Flow rate is the quantity of material that is moved per unit of time.  Generally, the quantity of material can be expressed as a mass or a volume.  For example, mass flow rates are in units of pounds per minute or kilograms per hour.  Volumetric flow rates are stated in cubic feet per minute or liters per hour.  The trick begins when volumetric flow rates are used for a compressible gas.  In this blog, I will go over the various acronyms and the reasons behind them.

What acronyms will be covered?

CFM – Cubic Feet per Minute

SCFM – Standard Cubic Feet per Minute

ACFM – Actual Cubic Feet per Minute

ICFM – Inlet Cubic Feet per Minute

The volumetric component of the flow rate is CFM or Cubic Feet per Minute.  This term is commonly used for rating air compressors.  From history of air compressors, they could calculate the volume of air being drawn into the air compressor by the size of cylinder.  With the volume of the compression chamber and the rotations per minute of the motor, RPM, they could calculate the volumetric air flows.  As conditions change like altitude, temperature, and relative humidity, the value of CFM changes.  To better clarify these conditions, compressor manufacturers decided to add terms with definition.  (For your information, air compressors still use CFM as a unit of air flow, but now this is defined at standard temperature and pressure).

The first letter in front of CFM above now defines the conditions in which the volumetric air flow is being measured.  This is important for comparing pneumatic components or for properly sizing pneumatic systems. Volume is measured with three areas: temperature, pressure, and relative humidity.  We can see this in the Ideal Gas Law: P * V = n * R * T or Equation 1:

V = n * R * T / P

V – Volume

n – Number of molecules of gas

R – Universal Gas Constant

T – Absolute Temperature

P – Absolute Pressure

The volume of air can change in reference to pressure, temperature, and the number of molecules.  Where is the relative humidity?  This would be referenced in the “n” term.  The more water vapor, or higher RH value, the less molecules of air is in a given volume.

SCFM is the most commonly used term, and it can be the most confusing.  The idea of this volumetric air flow is to set a reference point for comparisons.  So, no matter the pressure, temperature, or relative humidity, the volumetric air flows can be compared to each other at that reference point.  There have been many debates about an appropriate standard temperature and pressure, or STP.  But as long as you use the same reference point, then you can still compare the results.  In this blog, I will be using the Compressed Air and Gas Institute, CAGI, reference where the “Standard” condition is at 14.5 PSIA, 68 deg. F, and 0% RH.  Since we have a reference point, we still need to know the actual conditions for comparison.  It is like having a location of a restaurant as a reference, but if you do not know your current location, you cannot reach it.   Similarly, we are “moving” the air from its actual condition to a reference or “Standard” condition.  We will need to know where the air began in order to reach that reference point.  We will talk more about this later in this blog.

ACFM is the volumetric air flow under actual conditions.  This is actually the “true” flow rate.  Even though this term is hardly used, there are reasons why we will need to know this value.  We can size an air compressor that is not at “Standard” conditions, and we can use this value to calculate velocity and pressure drop in a system.  We can correlate between SCFM and ACFM with Equation 2:

ACFM = SCFM * [Pstd / (Pact – Psat Φ)] * (Tact / Tstd)

Where:

ACFM = Actual Cubic Feet per Minute
SCFM = Standard Cubic Feet per Minute
Pstd = standard absolute air pressure (psia)
Pact = absolute pressure at the actual level (psia)
Psat = saturation pressure at the actual temperature (psi)
Φ = Actual relative humidity
Tact = Actual ambient air temperature (oR)
Tstd = Standard temperature (oR)

ICFM is one of the newest terms in the history of air compressors.  This is where devices are added to the inlet of an air compressor, affecting the flow conditions.  If you have a blower on the inlet of an air compressor, the volumetric flow rate changes as the pressure and temperature rises at the “Inlet”.  If a filter is used, then the pressure drop will decrease the incoming pressure at the “Inlet”.  These devices that affect the volumetric flow rate for an air compressor should be considered.  The equation to relate the ACFM to ICFM is with Equation 3:

ICFM = ACFM * (Pact / Pf) * (Tf / Tact)

Where:

ICFM = Inlet Cubic Feet Per Minute

Pf  = Pressure after filter or inlet equipment (PSIA)

Tf = Temperature after filter or inlet equipment (°R)

Examples of these different types of flow rates can be found here in this EXAIR blog by Tyler Daniel.

To expand on my explanation above about SCFM and ACFM, a technical question comes up about the pressure when using SCFM.  The reference point of 14.5 PSIA is in the definition of SCFM.  Remember, this is only a reference point.  The starting location is actually required.  This would be the ACFM value where the air values are true and actual.  As an example, two air nozzles are rated for 60 SCFM.  An EXAIR Super Air Nozzle, model 1106, is cataloged at 80 PSIG, and a competitor is cataloged at 60 PSIG.  By comparison, they look like they use the same amount of compressed air, but actually they do not.  To simplify Equation 2, we can compare the two nozzles at the same temperature and RH at 68 Deg. F and 0% RH respectively.  This equation can be reduced to Equation 4:

ACFM = SCFM * 14.5 / (P + 14.5)

@60 PSIG Competitor:

ACFM = 60 SCFM * 14.5 PSIA/ (60 PSIG + 14.5 PSIA)

= 11.7 ACFM

@80 PSIG EXAIR Super Air Nozzle:

ACFM = 60 SCFM * 14.5 PSIA / (80 PSIG + 14.5PSIA)

= 9.2 ACFM

Even though the SCFM is the same amount, you are actually using 21% more air with the competitive nozzle that was reported at 60 PSIG.  So, when it comes to rating compressed air products or air compressors, always ask the conditions of pressure, temperature and RH.  The more you know about volumetric flow rates, the better decision that you can make.  If you need help, you can always contact our application engineers at EXAIR.

John Ball
Application Engineer
Email: johnball@exair.com
Twitter: @EXAIR_jb



Safety Air Guns – Using Engineered Air Nozzles For High Performance

Inexpensive air guns can be picked up just about anywhere, and you generally get what you pay for. Most will be very noisy and waste lots of compressed air.  And many will be unsafe, violating two of OSHA’s standards put in place to protect worker safety. The first is Standard 29 CFR 1910.95(a) which sets limits to the maximum noise exposure, and the second is Standard 29 CFR 1910.242(b) which says that the nozzle cannot be dead-ended, or exceed a 30 PSIG pressure limit.

These guns may seem like a perfect fit for a handheld blowoff application. The truth is, the cost saved up front will easily be paid throughout the cost of ownership.  This is due to the lack of an engineered nozzle which meets and exceeds the OSHA standards mentioned above.   The “cheap” guns often have a cross drilled hole to meet or exceed the OSHA standard for dead-end pressure. While this may be true, it causes a large wind sheer which escalates noise levels to well over the allowable noise level exposure set by OSHA.  These tips sometimes offer large force outputs because they are equivalent to an open pipe.  We have publicized numerous times about how an open pipe blow off does not permit pressure to be utilized all the way to the point of blowoff, and is also a waste of energy.

In order to determine how much compressed air your current blow guns utilize, the level of noise they product, and the sound level they produce, consider taking advantage of the EXAIR Efficiency Lab.  The Efficiency Lab is a free service that you can read more about here.

An EXAIR Safety Air Gun is engineered and designed to comply both of the OSHA standards mentioned above, ensuring safe operation for company personnel.  On top of the safety designed into the guns, we also ensure all of our guns are efficient by offering only engineered nozzles on them.

EXAIR offers (4) types of Safety Air Guns – the VariBlast, the Soft Grip, the Heavy Duty, and the Super Blast.  Each type of Safety Air Gun is offered with a plethora of nozzles, as well as varying length extensions, with or without the Chip Shield.

Safety Air Guns
The VariBlast, Soft Grip and Heavy Duty Style of Pistol Grip Safety Air Guns
Super Blast
The Super Blast Style of Safety Air Gun



We invite you to try out an EXAIR Safety Air Gun, and get the free 1″ Wide Flat Super Air Nozzle as a bonus. Click here for more details about this special promotional offer.

To discuss your application and how an EXAIR Intelligent Compressed Air Product can improve your process, feel free to contact EXAIR, myself, or one of our other Application Engineers. We can help you determine the best solution!

Brian Bergmann
Application Engineer

Send me an email
Find us on the Web
Like us on Facebook
Twitter: @EXAIR_BB

How To Propose A Cost Saving Strategy To Management

Chances are if you have been on your job for a little while, you have noticed some processes or equipment that takes excessive time, wastes energy, etc.. and delivers less than optimal results.  So, just how do you communicate those observations to management in your organization?  You certainly do not want to embarrass yourself by having your idea torpedoed, nor let the company continue wasting money on inefficient processes or equipment.  The question becomes, how do you present your cost savings plan to the management team?  This blog will help you with that very question!

Your idea(s) for cost savings should be presented clearly and concisely with some key information highlighting the cost and the savings.  The simplest way to accomplish this is to quantify the savings for a given period of time and the payback schedule.  The payback schedule is generally calculated by dividing the cost of the project by the forecast savings.  Generally speaking, the shorter the time required for payback, the better the odds of your project being approved.

To start the process generate a (1) page overview that states the problem, cost of your proposal and the forecast savings.  A thorough and concise presentation will help sway any naysayers in the group, and you should include detailed information that includes current operating costs and how you arrived at those figures.

In the compressed air industry, EXAIR Intelligent Compressed Air products provide some easy installations and quick payback times without sacrificing production or quality – in many cases, we can improve production and quality.  Let’s consider the case below, where open tubes were being used to blow off punch presses.  We started by capping off (4) of the open tubes and trying one EXAIR 1100 Air Nozzle with a defined air pattern and we clearly needed more force.  That is when we attached the second super air nozzle, and voila! We had the amount of force and the air pattern required for this application, all while greatly minimizing air consumption and noise!  The image below shows what a sample air savings presentation sheet or test sheet may look like.

Open Tube Cost Comparison

Considering the EXAIR 1100 Super Air Nozzle are $39 each, you can calculate that the payback time is slightly less than 10 working days per press, since two nozzles were used for each press.

When considering larger and more in-depth projects, naturally more documentation and information will be required.  In addition to the requirements for the above example, just be sure to include the following points:

  • List the action items for your proposal and any purchases that may be necessary.
  • Outline your proposed savings and document how you arrived at that number.
  • Discuss anything that may cause delays or not go as planned, and if possible, suggest viable workarounds.
  • Create a milestone schedule for all the major points in your plan.
  • Create illustrations.

If you would like to discuss increasing the efficiency of your compressed air usage, quieter compressed air products, and/or any EXAIR product,  I would enjoy hearing from you. Give me a call.

Steve Harrison
Application Engineer
Send me an email
Find us on the Web
Follow me on Twitter
Like us on Facebook











Wet Receivers and Condensate Drains

Receiver Tank

For properly designed compressed air systems, air compressors will use primary storage tanks, or receivers.  They are necessary to accommodate for fluctuations in airflow demand and to help prevent rapid cycling of the air compressor.  (Reference: Advanced Management of Compressed Air – Storage and Capacitance)  There are two types of primary receivers, a wet receiver tank and a dry receiver tank.  The wet receiver is located between the air compressor and the compressed air dryer where humid air and water will be stored.  The dry receiver is located after the compressed air dryer.  In this blog, I will be reviewing the wet receivers and their requirements as a storage tank.

Air compressors discharge hot humid air created by the internal compression.  A byproduct of this compression is water.  By placing a wet receiver on the discharge side of the air compressor, this will create a low velocity area to allow the excess water to fall out.  It will also give the hot air time to cool, allowing the compressed air dryers to be more effective.  With wet receivers, it will reduce cycle rates of your air compressors for less wear and store compressed air to accommodate for flow fluctuations in your pneumatic system.

But, there are some disadvantages with a wet receiver.  For compressed air dryers, it is possible to exceed the specified flow ratings.   If the demand side draws a large volume of air from the supply side, the efficiency of the compressed air dryers will be sacrificed, allowing moisture to go downstream.  Another issue with the wet receiver is the amount of water that the air compressor is pumping into it. As an example, a 60 HP air compressor can produce as much as 17 gallons of water per day.  As you can see, it would not take long to fill a wet receiver.  So, a condensate drain is required to get rid of the excess water.

Condensate drains come in different types and styles.  They are connected to a port at the bottom of the wet receiver where the water will collect.  I will cover the most common condensate drains and explain the pros and cons of each one.

  • Manual Drain – A ball valve or twist drain are the least efficient and the least expensive of all the condensate drains. The idea of having personnel draining the receiver tanks periodically is not the most reliable.  In some cases, people will “crack” the valve open to continuously drain the tank.  This is very inefficient and costly as compressed air is being wasted.
  • Timer Drain Valves – These valves have an electric timer on a solenoid to open and close a two-way valve or a ball valve. The issue comes in trying to set the correct time for the open and close intervals.  During seasonal changes, the amount of water going into the wet receiver will change.  If the timer is not set frequent enough, water can build up inside the receiver.  If too frequent, then compressed air is wasted.  Compared to the manual valve, they are more reliable and efficient; but there is still potential for compressed air waste.

    Timer Relay
  • No-waste Drains – Just like the name, these drains are the most efficient. They are designed with a float inside to open and close a drain vent.  What is unique about the float mechanism is that the drain vent is always under water.  So, when the no-waste drain is operating, no compressed air is being lost or wasted; only water is being drained.  The most common problem comes with rust, sludge, and debris that can plug the drain vent.

All wet receivers require a condensate drain to remove liquid water.  But, the importance for removing water without wasting compressed air is significant for saving money and compressed air.  EXAIR also has a line of Intelligent Compressed Air® products that can reduce your compressed air waste and save you money.  You can contact an Application Engineer for more details.

John Ball
Application Engineer
Email: johnball@exair.com
Twitter: @EXAIR_jb



Photo: Timer Relay by connectors distribution box.  Attribution – CC BY-SA 2.0

Estimating the Total Cost of Compressed Air

It is important to know the cost of compressed air at your facility.  Most people think that compressed air is free, but it is most certainly not.  Because of the expense, compressed air is considered to be a fourth utility in manufacturing plants.  In this blog, I will show you how to calculate the cost to make compressed air.  Then you can use this information to determine the need for Intelligent Compressed Air® products.

There are two types of air compressors, positive displacement and dynamic.  The core construction for both is an electric motor that spins a shaft.  Positive displacement types use the energy from the motor and the shaft to change the volume in an area, like a piston in a reciprocating compressor or like rotors in a rotary compressor.  The dynamic types use the energy from the motor and the shaft to create a velocity energy with an impeller.  (You can read more about air compressors HERE).  For electric motors, the power is described either in kilowatts (KW) or horsepower (hp).  As a unit of conversion, there are 0.746 KW in 1 hp.  The electric companies charge at a rate of kilowatt-hour (KWh).  So, we can determine the energy cost to spin the electric motors.  If your air compressor has a unit of horsepower, or hp, you can use Equation 1:

Equation 1:

hp * 0.746 * hours * rate / (motor efficiency)

where:

hp – horsepower of motor

0.746 – conversion to KW

hours – running time

rate – cost for electricity, KWh

motor efficiency – average for an electric motor is 95%.

If the air compressor motor is rated in kilowatts, or KW, then the above equation can become a little simpler, as seen in Equation 2:

Equation 2:

KW * hours * rate / (motor efficiency)

where:

KW – Kilowatts of motor

hours – running time

rate – cost for electricity, KWh

motor efficiency – average for an electric motor is 95%.

As an example, a manufacturing plant operates 250 day a year with 8-hour shifts.  The cycle time for the air compressor is roughly 50% on and off.  To calculate the hours of running time, we have 250 days at 8 hours/day with a 50% duty cycle, or 250 * 8 * 0.50 = 1,000 hours of running per year.  The air compressor that they have is a 100 hp rotary screw.  The electrical rate for this facility is at $0.08/KWh. With these factors, the annual cost can be calculated by Equation 1:

100hp * 0.746 KW/hp * 1,000hr * $0.08/KWh / 0.95 = $6,282 per year.

In both equations, you can substitute your information to see what you actually pay to make compressed air each year at your facility.

The type of air compressor can help in the amount of compressed air that can be produced by the electric motor.  Generally, the production rate can be expressed in different ways, but I like to use cubic feet per minute per horsepower, or CFM/hp.

The positive displacement types have different values depending on how efficient the design.  For a single-acting piston type air compressor, the amount of air is between 3.1 to 3.3 CFM/hp.  So, if you have a 10 hp single-acting piston, you can produce between 31 to 33 CFM of compressed air.  For a 10 hp double-acting piston type, it can produce roughly 4.7 to 5.0 CFM/hp.  As you can see, the double-acting air compressor can produce more compressed air at the same horsepower.

The rotary screws are roughly 3.4 to 4.1 CFM/hp.  While the dynamic type of air compressor is roughly 3.7 – 4.7 CFM/hr.  If you know the type of air compressor that you have, you can calculate the amount of compressed air that you can produce per horsepower.  As an average, EXAIR uses 4 CFM/hp of air compressor when speaking with customers who would like to know the general output of their compressor.

With this information, we can estimate the total cost to make compressed air as shown in Equation 3:

Equation 3:

C = 1000 * Rate * 0.746 / (PR * 60)

where:

C – Cost of compressed air ($ per 1000 cubic feet)

1000 – Scalar

Rate – cost of electricity (KWh)

0.746 – conversion hp to KW

PR – Production Rate (CFM/hp)

60 – conversion from minutes to hour

So, if we look at the average of 4 CFM/hp and an average electrical rate of $0.08/KWh, we can use Equation 3 to determine the average cost to make 1000 cubic feet of air.

C = 1000 * $0.08/KWh * 0.746 / (4 CFM/hp * 60) = $0.25/1000ft3.

Once you have established a cost for compressed air, then you can determine which areas to start saving money.  One of the worst culprits for inefficient air use is open pipe blow-offs.  This would include cheap air guns, drilled holes in pipes, and tubes.  These are very inefficient for compressed air and can cost you a lot of money.  I will share a comparison to a 1/8” NPT pipe to an EXAIR Mini Super Air Nozzle.  (Reference below).  As you can see, by just adding the EXAIR nozzle to the end of the pipe, the company was able to save $1,872 per year.  That is some real savings.

Compressed Air Savings

Making compressed air is expensive, so why would you not use it as efficiently as you can. With the equations above, you can calculate how much you are paying.  You can use this information to make informed decisions and to find the “low hanging fruit” for cost savings.  As in the example above, targeting the blow-off systems in a facility is a fast and easy way to save money.  If you need any help to try and find a way to be more efficient with your compressed air system, please contact an Application Engineer at EXAIR.  We will be happy to assist you.

John Ball
Application Engineer
Email: johnball@exair.com
Twitter: @EXAIR_jb



Cabinet Cooler NEMA Ratings Explained

CC_Actionshot

Temperatures are heating up across the US, when this happens it can wreak havoc on the sensitive electronics in your facility.  If you’re a follower of the EXAIR Blog, you’ve noticed that we’ve spent a great deal of time recently discussing the Cabinet Coolers. From a description of how they work, specific applications, as well as how to determine what size you’ll need, we’ve covered quite a range of topics. Equally important, though, is the NEMA rating of the Cabinet Cooler. I’d like to take a moment to discuss the different NEMA ratings for the Cabinet Coolers that EXAIR has to offer and where each should fit.

cc_heroi9_308x308
EXAIR’s Model 4008 Nema 12 Cabinet Cooler

NEMA 12 – The NEMA 12 rating is for enclosures that are indoor and provide a degree of protection to personnel against access to hazardous parts as well as prevent any materials from entering the enclosure such as dust, debris, or moisture from light splashing. This standard duty style of Cabinet Cooler is best served indoors on the shop floor where there aren’t any wash-down areas or excessive moisture.

EXAIR PR Hero Images
Model 4880-ETC120

NEMA 4 – A NEMA 4 rated cabinet cooler is designed for either indoor or outdoor use. It, too, provides protection to personnel against access to hazardous parts and prevents dust, dirt, or debris from entering the cabinet. In addition to providing the same levels of protection as the NEMA 12, the NEMA 4 rating also means that the equipment will be protected from water such as rain, sleet, snow, splashing water, and even hose directed water.

316DualCCcepr_559wide
Model 4880SS-316

NEMA 4X – The NEMA 4X carries the same levels of protection as the NEMA 4, but also adds an additional level of protection against corrosion. EXAIR’s NEMA 4X Cabinet Coolers are constructed of either 303 or 316 Stainless Steel.

EXAIR’s Cabinet Coolers are available from stock with cooling capacities ranging from 550 Btu/hr – 5,600 Btu/hr. With a variety of different materials and NEMA ratings, EXAIR has the right Cabinet Cooler ready to ship today to prevent your sensitive electronics from shutting down. Don’t let yourself get frustrated dealing with heat-related issues, get a maintenance-free Cabinet Cooler installed ASAP! Fill out the Cabinet Cooling Sizing Guide and an Application Engineer will be in touch with you within 24 hours with a quote for the most suitable model.

Tyler Daniel
Application Engineer
E-mail: TylerDaniel@EXAIR.com
Twitter: @EXAIR_TD

An Overview of the How EXAIR Cabinet Coolers Work



My colleague, Brian Bergmann wrote a blog on how the EXAIR Cabinet Coolers work, “Cabinet Coolers 101”.  I want to extend that conversation about how EXAIR Cabinet Coolers can better benefit you and your equipment.

With the hot summer months upon us, elevated temperatures can cause shutdowns and interference with electrical systems.  For every 10 deg. C rise above the operational temperature, the life of an electrical component is cut in half.  With freon based coolers, higher ambient conditions make them less effective; and opening the electrical panel to have a fan blow inside creates a dangerous electrical hazard as well as blowing hot, humid, dirty air inside the cabinet.  To reduce loss in production and premature equipment failures, it is important to keep the electrical mechanisms cool.  The EXAIR Cabinet Coolers are designed to do just that.

How does the Cabinet Cooler work?

EXAIR Cabinet Coolers are powered by a Vortex Tube which only uses compressed air to generate cold air.  They do not have any moving parts, freon to leak, or refrigerant compressors to fail.  These simple, but effective, cooling devices can be used in the toughest of environments.  With the Vortex Tube as the “engine, the reliability of the EXAIR Cabinet Cooler is unmatched and makes it an easy choice for cooling electrical panels.

How the EXAIR Cabinet Cooler System Works

What NEMA ratings does EXAIR offer?

To match the same integrity as your electrical panel, EXAIR offers three different types of NEMA ratings that are UL listed and CE compliant.  NEMA 12 is dust and oil tight, and can be related to the IEC standard, IP54.  NEMA 4 is dust and oil tight as well as splash resistant for indoor and outdoor use.  The NEMA 4X is the same as the NEMA 4 except it is made of stainless steel for corrosive areas and aggressive wash-down environments.  Both the NEMA 4 and 4x corresponds to an IP66 rating.  EXAIR Cabinet Coolers are easily installed and can match your electrical panel to keep the electrical components safe inside.

What size Cabinet Cooler do I need?

EXAIR makes it easy to get the proper cooling with the Cabinet Cooler Sizing Guide.  This sheet goes over the important information to determine the external and internal heat loads.  It also indicates the proper NEMA type and electrical requirements for easy installation. The cooling power ranges from 275 BTU/hr to 5,600 BTU/hr, and with the filled-out form, we can make sure that the correct model is used.

What types of systems are offered?

EXAIR offers a continuous operating system and a thermostat-controlled system.  The continuous operating system includes the selected Cabinet Cooler, a filter, and a cold air distribution kit.  The system will continuously cool until it is manually or automatically turned off.

The thermostat-controlled system is the most efficient way to operate a Cabinet Cooler.  This system comes with the selected Cabinet Cooler, filter, cold air distribution kit, a thermostat and an electrical solenoid valve.  The system is designed to operate only when cooling is needed.  The thermostat controls a solenoid valve, and it is preset at 95°F (35°C).  The thermostat can be easily adjusted to match other desired temperatures.  The solenoid valves come in three different voltages, 120Vac, 240Vac, and 24Vdc (which ever voltage is easily accessible).  With the thermostat-controlled system, you do not have worry about the system operating during off-peak conditions or cooler seasons.

What other options does EXAIR offer with the Cabinet Cooler Systems?

For better temperature control, EXAIR can replace the standard thermostat and solenoid valve with the ETC, or Electronic Temperature Control.  It is a digital temperature controller with a LED screen for precision monitoring and adjusting.  The controller has easy-to-use buttons to raise or lower the desired internal cabinet temperature.  Once set, the ETC will hold the temperature to +/- 1 deg. F (+/- 0.5 deg. C).  The LED displays the internal temperature for continuous monitoring.  The ETC comes complete with the controller and a solenoid valve in two different voltages, 120Vac and 240Vac.  The ETC is a great option for real-time accurate measurements for your panel cooling.

EXAIR NEMA 4X 316SS Cabinet Cooler System with Electronic Temperature Control installed on control panel in a pharmaceutical plant.

Another option that EXAIR offers is the Side Mount Kit.  They are used to mount the Cabinet Coolers on the side of the electrical panel.  They are manufactured to match the NEMA rating of the Cabinet Cooler.  If you have limited space, don’t worry.  The Side Mount Kits gives you more areas to mount the Cabinet Cooler to your electrical panel.

What about harsh environments?

With elevated ambient temperatures like near ovens, the high temperature version would be your option.  The HT Cabinet Coolers work in temperatures from 125 deg. F to 200 deg. F (52 deg. C to 93 deg. C respectively).  With refrigerant coolers, the elevated temperatures make it very difficult to cool effectively.  But with the EXAIR HT Cabinet Coolers, the high temperature will not affect the ability to blow cool air.

If the environment is extremely dirty with lint, fibers, debris, etc., EXAIR offers a NHP, or Non-Hazardous Purge, version. The solenoid valve is designed to allow 1 SCFM of compressed air into the panel to keep a slight positive pressure.  With the NHP Cabinet Coolers, the ingress of any fine particles into your electrical panel are eliminated.

For food and beverage, pharmaceutical, and corrosive type of applications, EXAIR can offer NEMA 4X Cabinet Coolers made from 316SS material.  With the high corrosion resistance, the 316SS Cabinet Coolers will continue to operate without degrading in tough environments.

Electrical shutdowns are expensive and annoying.  If you have interruptions from high internal temperatures, EXAIR Cabinet Coolers are a great solution.  They can be installed quickly and easily.  With no moving parts or costly preventative maintenance needed, they can operate for decades in keeping your electronics cool.  If you have any questions about Cabinet Coolers or the Sizing Guide, you can contact an Application Engineer at EXAIR.  We will be happy to help.

John Ball
